5 OUTPUT TEST
6 TEST ALL
7 KEYBOARD
Table 3-9.
Manual of NCH02
to a color block, the valid color block becomes red, and the
invalid color is blackened.
The output IO value is displayed in real time. One IO
corresponds to a color block, the output block becomes red, and
the invalid color is blackened.
The function is selected by the adjustment knob. After the test is
started (PUSH), all modules are running or changing according
to the design.
Button monitoring can monitor the press position in real time.
Description of test and diagnosis page
