Test And Diagnosis Page - Novusun CNC NCH02 Manual

16 ESTOP PIN
17 ESTOP LEVEL
18 P-B-Z

3.4 Test and diagnosis page

The test and diagnosis page can be entered by pressing
configuration page. The page mainly displays the basic function test information of the system,
including key monitoring, input and output monitoring, spindle monitoring and so on. Page
reference diagram 3-7. detailed description of reference table 3-9.
Manual of NCH02
The pin of Estop, 0 for closing, and 1-8 for the
corresponding input pin IN1-IN8
Effective level of Estop, 1: high efficiency, 0:
low efficiency
Back distance of Z axis after Probe in
floating-position mode
Table 3-8. Other parameter setting
- 33 -
www.nvcnc.net
0-8
1/0
0-100
under the parameter
