Novusun CNC NCH02 Manual page 34

No. Mark
5 PROBE-PIN
6 PROBE-LEVEL Effective level of Probe, 1: high efficiency, 0: low
7 PROBE-MOD
8 P-X
9 P-Y
10 P-Z
11 PROBE SPD
No. Mark
12 Language
13 Home Spd
14 BL Speed
15 Buzzer
Manual of NCH02
Definition
The pin of Probe, 0 for closing, and 1-8 for the
corresponding input pin IN1-IN8
efficiency
Probe mode,
1:floating-position probe
X axis coordinate of Tool sensor in fixed-position
mode
Y axis coordinate of Tool sensor in fixed-position
mode
Z axis coordinate of Tool sensor in fixed-position
mode
Probe speed ratio according to G0
Table 3-7. Configuration of Probe
Definition
Language settings (temporary support for
English only)
Home speed ratio according to G0
Backlash speed ratio according to G0
Button buzzer switch, 0: close, 1: open
- 32 -
www.nvcnc.net
0:fixed-position probe,
Range
0-8
1/0
1/0
±10000
±10000
±10000
0-100%
Range
0
0-100%
0-100%
1/0
