The adjustable parameters are described below, and all the adjustable
parameters can be selected by the knob Clockwise rotation or a reversal.
Under normal conditions, the adjustable parameters are white background black
words.
When turning the knob, you can see the valid position is changed with the knob,
a parameter change to blue background and white word when it become a valid
parameter.
When a parameter - we need to modify the value when it is selected. we need to
click the PUSH (button of the knob), then the parameters become black background
and white word, meaning it's in editing, we can modify the parameters according to
the number keys.
After the modification, then press the PUSH, then it exit the edit state and enter
the unselected state, then the parameter displays the adjusted value.
5, FRO parameter setting
FRO is a feed rate adjustment that can be adjusted through the knob, adjusting the range
from 0~200%, and the actual feed speed #F=FRO*F (F is feed speed set value).
6, SRO parameter setting
SRO is the spindle rate adjustment, can be adjusted through the knob, the adjustment range
from 0~200%, the actual spindle speed #S=SRO*S (S is the spindle speed set value).
7, SJR parameter setting
SJR is a manual speed rate adjustment that can be adjusted through the knob, adjusting the
range from 0~100%, the actual manual speed #HF=SJR*HF (HF is the manual speed set value).
8,Step manual mode single step parameter setting
