12.
Replace the cable conduit access plate and tighten the two retaining screws.
NOTE: The cable conduit access plate can be positioned in one of two ways
depending on installer preference. Flip the plate to the desired position with the
wire openings either on the side or on the top of the back can before tightening
the screws.
As examples:
•
The side access wire opening can be useful in low profile installations.
•
The top access wire opening can be more convenient to use.
13.
Tighten the cable clamp if it was used.
14.
Mount the speaker back can enclosure.
a.
Insert the back can through the bottom of the hole in the ceiling tile that was cut in
step 6
on page 17 with the wires out of the way.
Figure 25.
Inserting the Speaker Back Can
OR
SF 3C LP and SF 3CT LP User Guide • Installation
24
