Using a conduit adapter on the cable conduit access plate:
Flexible Conduit Ad d apter Flexible Conduit Adapter
Figure 9. Using a Conduit Adapter
g. Replace the cable conduit access plate and tighten the two retaining screws.
NOTE: The cable conduit access plate can be positioned in one of two ways
depending on installer preference. Flip the plate to the desired position with
the wire openings either on the side or on the top of the speaker enclosure
before tightening the screws.
As examples:
• The side access wire opening can be useful in low profile installations.
• The top access wire opening can be more convenient to use.
h. Tighten the cable clamp if it was used.
OR
SF 3C LP and SF 3CT LP User Guide • Installation 11
