9. APPENDIX B - EWIS 4100 FAULT MESSAGES

9.1 CARD TROUBLES

If the LCD displays ... Wrong Card Abnormal
1st Line Shows Card Expected at this Address.
Reprogram System or Insert Proper Daughter Card.
If the LCD displays ... Extra Card Abnormal
A Daughter Card is/was installed but not Programmed.
Reprogram System or Remove Extra Daughter Card.
Warm Start is Necessary to Clear this Trouble Condition. Press the CPU
Reset Switch located on the Master Controller Board.
If the LCD displays ... Card Missing/Failed
Identify Card from LCD.
Is Communication Trouble LED illuminated on Card ?
Check Dipswitch Setting with Programmer's Report.
Check for 8VDC & 24VDC at Motherboard Harness P3.
Check for Serial Comm at Motherboard Harness P2.
If ALL Daughter Cards Report Missing/Failed Check Serial Comm fuse on
Master Controller Board (F6).
If this Trouble only Occurs upon Alarm, Alarm Silence or System Reset it may be
Caused by Unsuppressed Relays, Door Magnets, High Current Loads, etc.
