Close and lock the panel door.
10.
All system electronics shipments include a small cardboard box (or boxes) containing
the system cards. Each box is marked as shown in Figure 2
Install the system cards in the system electronic bays after installation of the back
box and completion of the system field wiring.
To install the system cards, perform the following procedure:-
1. Make sure that the system ground wire is attached to the green lug screw in
the back box.
2. Inventory the contents of the system card box(es) on a flat surface.
• Open the system card box(es) and remove the cards.
• Refer to the factory documentation that accompanies the shipment.
3. Carefully install the Master Controller Card in the left hand slot on the Master
Motherboard, located in the CPU bay (See Figure 3.)
4. 4100 Panels: Carefully install the RS-232/2120 Communication Card
(if Supplied) in the right hand slot on the Master Motherboard (See Figure 3).
5. 4120 Network Panels: Carefully install the RS-485 Network Interface Card in the
right hand slot on the Master Motherboard (See Figure 3).
Document No.: 4100-M011
-CAUTION-
INSTALLER
THIS PACKAGE CONTAINS
CRITICAL COMPONETS
FOR INSTALLATION INTO ,
AND OERATION OF,
THIS UNIT

Figure 2 System Card Box Label
