4.3 SYSTEM POINT SUMMARY

The System Point Summary is of primary importance to the installer.
personnel must provide this information prior to installation. Call your local Simplex
branch office, which is listed in the Yellow Pages, and request this information be
provided. This is used in conjunction with the Layout pages, to determine wiring
terminations and the information shown below.

4.3.1 Zone Name

Zone names reference the custom label to specific points for actual customer wiring.
They include monitor zones (ZNx), signals (SIGx), auxiliary relays (AUXx), 24 point
I/O (PMx) and feedback (FBx) numbers. Zones, signals, relays, feedbacks, etc., are
shown in numerical sequence.

4.3.2 Address

Each printed circuit board requires a unique address.
master termination module. Up to 119 addresses, one per printed circuit board, may
be used in a system. Addresses may or may not be in sequential order, but the
report always starts with address 0.
mother/daughter board combination. The mother board will have its unique address
label next to the PC board connector. The daughter board will have an identical
label.

4.3.3 Custom Label

The custom label identifies a location within the building or area, and contains
additional information concerning each circuit. Also included with the custom label is
the corresponding zone name. This ties the custom label to a zone name and allows
the installer to identify where field wires are terminated, according to zone name.
Examples:

4.3.4 Point Type

This is the type of device (indicating appliance, initiating device, relays, etc.)
connected to each circuit.
description may also be included in the abbreviation.
Example:
The installer should use the System Point Summary when marking wires to the 4100
panel. These markings should include zones (ZNx+, ZNx--), signals (SIGx), etc., for
each circuit within the system.
termination and checking of the wiring in the 4100 panel.
