5-49. Payload ID (FA-96EX3G44-R / FA-96SFPC4)

The Payload ID (Slot A) page is displayed when FA-96EX3G44-R or FA-96SFPC4 is installed.
SDI signal
SD
Display
Link A data No display
Link B data No display
If no SFP modules are inserted into FA-96SFPC4 cages, "Not Installed" is displayed.
Required
Option
HD 3G Level A
Payload ID Payload ID
in Y signal in Y signal
Payload ID
No display
in C signal
80
Simultaneous 4K/HD
Dual HD
3D-LUT (FS1)
FA-96EX3G44-R
FA-96SFPC4
3G Level B
Payload ID
in Link A
Payload ID
in Link B
