  • Page 1 OPERATION MANUAL UFH-70DAC HD/SD D/A Converter Edition - Rev.2...
  • Page 3 Precautions Important Safety Warnings [Power] Do not place or drop heavy or sharp-edged objects on power cord. A damaged cord can cause fire or electrical shock hazards. Regularly check power cord for excessive wear or damage to avoid possible fire / electrical hazards. Stop [Circuitry Access] Do not touch any parts / circuitry with a high heat factor.
  • Page 4 Upon Receipt Unpacking UFH-70DAC HD/SD D/A converter and their accessories are fully inspected and adjusted prior to shipment. Operation can be performed immediately upon completing all required connections and operational settings. Check your received items against the packing lists below.

  • Page 5: Table Of Contents

    Table of Contents 1. Prior to Starting ...........................1 1-1. Welcome ..........................1 1-2. Features..........................1 2. Panel Descriptions ........................2 2-1. Front Panel .........................2 2-2. Rear Panel..........................3 3. Connection..........................4 4. Operations ..........................5 4-1. Power On..........................5 4-2. Front Panel Controls ......................6 4-2-1. UNITY/OPERATE .......................6 4-2-2.

  • Page 7: Prior To Starting

    Whatever your needs, talk to your FOR-A representative. We will do our best to be of continuing service to you. 1-2. Features The UFH-70DAC is a module-type D-to-A Converter that can be installed in a UFH frame. It can convert HD-SDI and SD-SDI signals into analog signals. Conversion of HD-SDI and SD-SDI signals into analog signals...

  • Page 8: Panel Descriptions

    2-1. Front Panel POWER PROCESS CONTROL FUNCTION INPUT UNITY 6 7 8 VIDEO LEVEL CHROMA LEVEL SETUP/BLACK CHROMA PHASE UFH-70DAC ERATE UFH-70DAC (1) (2) (3) (4) (5) (6) (7) Name Description Refer to Power is supplied to the unit. ― POWER LED Unlit Power is not supplied to the unit.

  • Page 9: Rear Panel

    Y/G/C1 P /B/C2 P /R/C3 SYNC/C4 HD/SD-SDI IN HD/SD ANALOG OUT UFH-70DAC Name Description The left connector is used to input a serial digital component signal (HD/SD-SDI). HD/SD-SDI IN The right connector is active through output of HD/SD-SDI IN. The...

  • Page 10: Connection

    HD-SDI signal SD-SDI signal HD/SD-SDI IN HD/SD-SDI OUT ANALOG OUT Y / G / C1 ANALOG OUT / B / C2 UFH-70DAC ANALOG OUT HD/SD-SDI Monitor / R / C3 or other device Analog Monitor ANALOG OUT or other device...

  • Page 11: Operations

    3 4 5 6 UFH-70MUX POWER POWER LOCK (PUSH) UFH-70MUX V.CHK OPERATE 3 4 5 6 UFH-70DEMUX POWER POWER LOCK (PUSH) UFH-70DEMUX POWER INPUT PROCESS CONTROL FUNCTION UNITY VIDEO LEVEL CHROMA LEVEL SETUP/BLACK CHROMA PHASE 6 7 8 UFH-70DAC ERATE SER.NO. UFH-70DAC...

  • Page 12: Front Panel Controls

    4-2. Front Panel Controls 4-2-1. UNITY/OPERATE Set the switch to the upper or lower positions to switch between UNITY and OPERATE. Switch and Controls Description All process control settings are disabled and return to the PROCESS CONTROL default settings. Upper UNITY VIDEO SETUP/...

  • Page 13: Chroma Level

    4-2-3. CHROMA LEVEL Switch and Controls Description Adjusts chroma level. UNITY/OPERATE: Chroma Level controls how PROCESS CONTROL Lower position much color (saturation) is (OPERATE) increased or decreased. UNITY VIDEO SETUP/ CHROMA CHROMA LEVEL LEVEL BLACK PHASE Setting range: -3dB to +3dB Turn the CHROMA When the control is set to the LEVEL control to...

  • Page 14: Dipswitch Setting (Function)

    4-3. Dipswitch Setting (FUNCTION) Setting Factory Pin No. Item OFF (Up) ON (Down) 1=OFF, 2=OFF: SW2-1 1=ON, 2=OFF: Analog output selection 1 1=OFF, 2=ON: SW2-2 1=ON, 2=ON: Composite SW2-3 Analog output selection 2 Composite SYNC ― ― ― SW2-4 Output selection when SW2-5 BLACK NO SIGNAL...

  • Page 15: Detailed Setting For Analog Output

    4-3-1. Detailed Setting for Analog Output Analog output signals can be set manually as shown in the table below by the dipswitches SW2-1, SW2-2, and SW2-3. Switch Setting Analog Output Signal Y/G/C1 /B/C2 /R/C3 SYNC/C4 Input Y (SD) B-Y (SD) R-Y (SD) Composite Bi-level...

  • Page 16: Internal Settings

    5. Internal Settings 5-1. Dipswitch Settings The following settings can be made at the dipswitches (SW5, SW6 and SW7) on the front module of the UFH-70DAC. Rear module Front module SW5 Setting Setting Pin No. Item Factory Set ― ―...
  • Page 17 SW6 Setting Setting Factory Pin No. Item SW6-1 SW6-2 Input signal format (See below.) SW6-3 SW6-4 SW6-5 SW6-6 Setup 0 IRE 7.5 IRE SW6-7 Component signal level BETACAM SMPTE SW6-8 Test signal selection Color Bar Cross Hatch Input signal format ( SW6-1 to SW6-5 ) Selects the input signal format.
  • Page 18 SW7 Setting Setting Factory Pin No. Item ― ― ― SW7-1 ― ― ― SW7-2 SW7-3 Mono/Color output Color Mono ― ― ― SW7-4 ― ― ― SW7-5 ― ― ― SW7-6 GBR output w/ sync SW7-7 or w/o sync ―...

  • Page 19: Specifications And Dimensions

    6. Specifications and Dimensions 6-1. Unit Specifications Standards HD-SDI 1080/59.94i, 720/59.94p, 1080/50i, 720/50p, 1080/60i, 720/60p, 1035/59.94i, 1035/60i SD-SDI 525/59.94, 625/50 Video Inputs HD/SD-SDI 1.485G / 270Mbps, 75Ω, BNCx1 Video Outputs HD/SD-SDI 1.485G / 270Mbps, 75Ω, BNCx1 (active through) Analog 75Ω, BNCx4 (refer to below) - YP (HD/SD) Y:1.0Vp-p, P...

  • Page 20: External Dimensions

    C H R O M A L E V E L S E T U P / B L A C K C H R O M A P H A S E U F H - 7 0 D A C O P- ERATE UFH-70DAC...
  • Page 21 Warning This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications.
  • Page 22 Two Executive Drive, Suite 670, Fort Lee Executive Park, Fort Lee NJ 07024, USA Phone: +1 (201) 944-1120 Fax : +1 (201) 944-1132 FOR-A America Distribution & Service Center 2400 N.E. Waldo Road, Gainesville, FL 32609, USA Phone: +1 352-371-1505 Fax: +1 352-378-5320...
