- Page 1 OPERATION MANUAL DCC-100 Digital Color Corrector Edition...
- Page 3 Precautions Important Safety Warnings [Power] Operate unit only on the specified supply voltage. Caution Disconnect power cord by connector only. Do not pull on cable portion. Do not place or drop heavy or sharp-edged objects on power cord. A damaged cord can cause fire or electrical shock hazards.
- Page 4 [Circuitry Access] Do not remove covers, panels, casing, or access circuitry with power applied to the unit! Turn power off and disconnect power cord prior to removal. Internal servicing / adjustment of unit should only be performed by qualified personnel. Do not touch any parts / circuitry with a high heat factor.
-
Page 5: Rack Mounting
Rack Mounting The DCC-100 can be either single unit or dual unit mounted to EIA standard rack units. Racking mounting requires purchase of one of the two available rack mount kits. When single unit mounting the single mount kit with one extended rack ear must be used. When two units mounting the dual mount kit with standard size rack ears must be used. -
Page 6: Table Of Contents
Table of Contents 1. Prior to Starting........................... 1 1-1. Welcome ..........................1 1-2. Features ..........................1 1-3. About This Manual......................1 2. Panel Descriptions ........................2 2-1. Front Panel......................... 2 2-2. Rear Panel ......................... 3 3. Connection ..........................4 3-1. Connection Example 1 ....................... 4 3-2. -
Page 7: Prior To Starting
FOR-A provides a wide range of products, from basic support units to complex system controllers, which have been increasingly joined by products for computer video based systems. Whatever your needs, talk to your FOR-A representative. We will do our best to be of continuing service to you. -
Page 8: Panel Descriptions
Indicates that no power is supplied to the POWER Unlit system. Flashing Indicates a fan failure occurs in a power (Fan Alarm) supply. Consult your FOR-A supplier. Receiving composite signal input and the Lit green unit is working properly. COMPOSITE IN No input video signals. Unlit Input level too low. -
Page 9: Rear Panel
2-2. Rear Panel REMOTE COMPOSITE SD-SDI SD-SDI 1 SD-SDI 2 COMPOSITE 1 COMPOSITE 2 INPUT OUTPUT UFM-100DCC (1) INPUT COMPOSITE Used to input analog composite video. SD-SDI Used to input SD-SDI signal. (2) OUTPUT Used to output processed SD-SDI signal. Used to bypass the signal SD-SDI 1 from (1) INPUT SD-SDI whenever the unit power is off. -
Page 10: Connection
3. Connection 3-1. Connection Example 1 Use the supplied control cable (PC-2076-2) to connect a DCC-OU or a DCC-OUA to the DCC-100. Input both SD-SDI and analog composite video signals and perform correction by switching them. Connection DCC-OU TO MU1... -
Page 11: Connection Example 2
TO MU2 TO MU3 TO MU4 POWER AC100-117V ~ 50/60Hz IN PU SH RATING LABEL PC-2076-2 (10m) Analog monitor SD-SDI Camera COMPOSITE DCC-100 REMOTE COMPOSITE SD-SDI SD-SDI 1 SD-SDI 2 COMPOSITE 1 COMPOSITE 2 INPUT OUTPUT UFM-100DCC Reference (BB) Digital... -
Page 12: Operation
POWER lamp SD-SDI-IN lamp 4-2. Front Panel Operations The DCC-100 front panel controls can be used to select video input (INPUT SELECT) and split display mode (SPLIT). 4-2-1. INPUT SELECT Set the switch to the upper or lower positions to switch the input video standard. -
Page 13: Split
Move the switch to upward or downward to select split screen mode for COMPOSITE OUT1, COMPOSITE OUT2, SD-SDI OUT 1 and SD-SDI OUT 2, which allows direct comparison of images before and after correction. (When operating with DCC-OUA, change split mode from DCC-OUA.) DCC-100 DIGITAL COLOR CORRECTOR INPUT SELECT SPLIT... -
Page 14: Remote Control
DCC-100 rear panel. Refer to DCC-OU or DCC-OUA operation manual for details on color correction operation. IMPORTANT The dipswitch SW2 inside the DCC-100 must be set according to which operation unit is used. See section 5-1-2. "SW2." 4-3-1. REMOTE Connector... -
Page 15: Internal Setting
5. Internal Setting 5-1. Dipswitch Settings Following settings can be made at dipswitch SW1, SW2, and SW3 on the MAIN CARD. MAIN CARD I/O CARD 5-1-1. SW1 Dipswitch SW1 Setting Pin No Function ― TEST SIGNAL COLOR BAR SYNCHRO MODE INPUT FRAME SPLIT OFF (Composite OUT) - Page 16 NOTE If set to INPUT: The amount of jitter on the SD-SDI output depends on that of input signal when analog composite is selected for input. Color framing is not always properly processed for COMPOSITE output when the SD-SDI input is used. If set to FRAME: The composite input is horizontally locked, however, it is not correctly locked to the subcarrier of the applied genlock.
-
Page 17: Sw2
(Default) INPUT SELECT (front panel), SPLIT (front panel) and GAMMA MODE (dipswitch SW2) must be set not from DCC-100 but from DCC-OUA. GAMMA MODE (SW2-2, SW2-3) Select the suitable type of gamma correction from the following three adjustments with two dipswitches. - Page 18 Gamma Mode 50％ If Center is selected (default) Correction Range If Black is selected 25％ Correction Range 75％ If White is selected Correction Range...
-
Page 19: Sw3 (Setup Setting)
5-1-3. SW3 (SETUP Setting) Dipswitch SW3 Setting Pin No. Function SETUP ― ― FACTORY SET ― ― FACTORY SET ― ― FACTORY SET ― ― FACTORY SET ― ― FACTORY SET ― ― FACTORY SET ― ― FACTORY SET * Shaded cells indicate factory default. SET UP (SW3-1) Selects setup 0 or 7.5. -
Page 20: Jumper Settings
5-2. Jumper Settings The following settings can be made at the jumpers on MAIN CARD inside the DCC-100. MAIN CARD I/O CARD Factory Default Settings JP NO. Factory Default Open 3-4 short 1-2 short * Do not change JP1 and JP3. -
Page 21: If Problems Occur
"SW2." Cannot operate front panel. INPUT SELECT and SPLIT cannot be set With DCC-OUA from DCC-100 front panel. Set them from DCC-OUA. If dipswitch SW2-1 is set to DCC-OUA(ON), Cannot make With DCC-OU change to DCC-OU (OFF). See section 5-1-2. -
Page 22: Specifications & Dimensions
7. Specifications & Dimensions 7-1. Unit Specifications Standard 525/60 (NTSC) , 625/50 (PAL) (Auto detection) Signal Processing 4:2:2 component Correction Range 2 field (field inversion prevented) Sampling Frequency Y: 13.5MHz, C: 6.75MHz Quantization 10-bit Video Input 270Mbps, 75Ω, BNC, 1 input Analog composite 1.0 Vp-p, 75Ω, BNC, 1 input Video Output... - Page 23 Color Correction (operated from DCC-OU or DCC-OUA) Correction mode Balanced, Differenctial, Sepia White level (RGB) 50% to150% (based on input signal) Black level (RGB) 50% to 150% (based on input signal) Gamma level (RGB) 75 to125% (based on input signal) Color Gamut Control (operated from DCC-OU or DCC-OUA) Y White clip 50% to 109%...
-
Page 24: External Dimensions
7-2. External Dimensions 7-2-1. Single Unit All dimensions in mm DCC-100 DIGITAL COLOR CORRECTOR INPUT SELECT SPLIT COMPOSITE COMPOSITE IN POWER SD-SDI IN SD-SDI POWER... -
Page 25: Rack Mounting Examples
7-2-2. Rack Mounting Examples All dimensions in mm Dual unit M4 BIND SCREW 12 20 12 DCC-100 DCC-100 DIGITAL COLO R CORRECTOR DIGITAL COLOR CORRECTOR INPUT SELECT SPLIT INPUT SELECT SPLIT COMPOSI T E COMP OSI T E COMPOSI T E I N... - Page 27 Warning This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications.
- Page 28 Two Executive Drive, Suite 670, Fort Lee Executive Park, Fort Lee NJ 07024, USA Phone: +1 (201) 944-1120 Fax : +1 (201) 944-1132 FOR-A America Distribution & Service Center 2400 N.E. Waldo Road, Gainesville, FL 32609, USA Phone: +1 352-371-1505 Fax: +1 352-378-5320...
