WARNING:
FIRE OR EXPLOSION HAZARD
Failure to follow safety warnings exactly could result in serious injury,
death, or property damage.
— Do not store or use gasoline or other flammable vapors and
liquids in the vicinity of this or any other appliance.
— WHAT TO DO IF YOU SMELL GAS
•
Do not try to light any appliance.
•
Do not touch any electrical switch; do not use any
phone in your building.
• Leave the building immediately.
• Immediately call your gas supplier from a neighbour's
phone. Follow the gas supplier's instructions.
• If you cannot reach your gas supplier, call the fire
department.
— Installation and service must be performed by a qualified
installer, service agency or the gas fitter.
DANGER
HOT GLASS WILL CAUSE BURNS.
DO NOT TOUCH GLASS UNTIL
NEVER ALLOW CHILDREN
A barrier designed to reduce the risk of burns
from the hot viewing glass is provided with this
appliance and must be installed for the protection
of children and other at-risk individuals.
Installation & Maintenance Manual
®
C
US
COOLED.
TO TOUCH GLASS.
DelRay Square
INDOOR DIRECT VENT GAS FIREPLACE
DRSQC38NI CONTEMPORARY
DRSQC38LI CONTEMPORARY
DRSQC38NI-2 CONTEMPORARY
DRSQC38LI-2 CONTEMPORARY
Installation and service must be performed by a qualified installer,
service agency or the gas fitter. Check local codes and read all
instructions prior to installation.
NOTICE
Installer: Leave this manual with the appliance. Please refer to the
Montigo website for the most current version of the fireplace manual
Consumer: Retain this manual for future reference. Please refer to the
Montigo website for the most current version of the fireplace manual
WARNING
Some materials used in the manufacturing process of this product can
expose you to Benzene which is known in the State of California to
cause cancer and birth defects or other reproductive harm. For more
information go to www.P65warnings.ca.gov
DRSQ38NI TRADITIONAL
DRSQ38LI TRADITIONAL
DRSQ38NI-2 TRADITIONAL
DRSQ38LI-2 TRADITIONAL
XG0230 - 052020
Advertisement
Table of Contents
Related Manuals for Montigo DelRay Square Series
Summary of Contents for Montigo DelRay Square Series
- Page 1 DANGER Installer: Leave this manual with the appliance. Please refer to the Montigo website for the most current version of the fireplace manual Consumer: Retain this manual for future reference. Please refer to the HOT GLASS WILL CAUSE BURNS.
-
Page 2: Safety Alert Key
DRSQC38LI-2 61.54% Congratulations on your purchase of a Montigo Fireplace. With over 30 years of experience, Montigo is committed to providing BTU Listing you with a gas fireplace that is not only a beautiful addition to your space, but that is also designed and manufactured to the highest safety, reliability and engineering standards. -
Page 3: Table Of Contents
General This appliance may be installed in an aftermarket, permanently located, manufactured home (USA only) or mobile home, where not prohibited by local codes. This appliance is only for use with the type of gas indicated on the rating plate. A conversion kit is supplied with the appliance. Contents Safety Alert Key .................. 2 Gas Pressure ....................21 Introduction ..................2 Section 5-3: GAS CONNECTION ..............21 Efficiency ..................... -
Page 4: Section A: Before You Begin
• Should it be impossible to meet the venting requirements laid out in Section 3: Venting, please contact your Montigo dealer regarding the use of a Montigo Power Vent. NOTICE •... -
Page 5: Standard Installation Checklist
General Standard Installation Checklist This standard installation checklist is to be used by the installer in conjunction with, not instead of, the instructions contained within this installation manual. Customer Date Installed: Install Address: Location of Fireplace: Installer: Dealer Phone: Model (circle one): DRSQ38NI, DRSQ38NI-2, DRSQ38LI, DRSQ38LI-2, Serial #: IF NO, WHY NOT? -
Page 6: Rating Plate Sample
General Rating Plate Sample Figure 1.1 Rating Plate for DelRay DRSQ38NI Figure 1.2 Rating Plate for DelRay DRSQ38NI-2 XG0230 - 052020... -
Page 7: Section 1: Dimensions
Installation Section 1: Dimensions DelRay Square Dimensions BASIC MODELS DRSQ38NI DRSQC38NI DRSQ38LI DRSQC38LI 526.298 FULL LOAD MODELS 4 " DRSQ38NI-2 DRSQC38NI-2 201.473 POWER DRSQ38LI-2 DRSQC38LI-2 SUPPLY 16 " 419.075 2 " 12.548 SUPPLY 2 " 857.758 4 " 431.470 1015.086 17"... -
Page 8: Section 2: Framing
Installation Section 2: Framing In Wall and Corner Dimensions Rear vent, rigid or flex 1). Frame in the enclosure for the unit with framing materials. The 16 " OUTDOOR framed opening for the assembled fireplace shown below in table WALL MIN. 2 " NOTE: When constructing the framed opening, please ensure there is MIN. -
Page 9: Clearances
Installation Section 3: Venting Clearances Montigo offers a variety of direct venting and termination options. The direct vent termination location MUST be selected such that it is the highest point in the venting assembly. It should also be selected such When installing a shelf over the top of the fireplaces, the following that it provides the shortest vent run possible. -
Page 10: Restrictor Plate
Installation Restrictor plate Primary air adjustment The fireplace is equipped with a factory installed restrictor set at fully During initial installation, check primary air opening open. If fireplace vent is terminated horizontally, NEVER CLOSE the (below are factory settings): restrictor completely. Adjust the restrictor opening by judging flame DRSQ38*I 3/16”... -
Page 11: Section 3-3-1: Venting Layout
Installation Section 3-3-1: Venting Layout DRSQ38 5/8 TOP Venting - DRSQ38 4/7 TOP Venting - Wall and roof termination Wall and roof termination Maximum total vent run allowed is 34 ft. (V+H ≤ 34ft.) Maximum total vent run allowed is 34 ft. (V+H ≤ 34ft.) For longer vent runs, a power vent is required For longer vent runs, a power vent is required V + H are measured from the center of vent elbows V + H are measured from the center of vent elbows Elbow may be attached directly to the top of the unit. -
Page 12: Drsq38 Rear Venting
Installation DRSQ38 Rear Venting A maximum 18" of horizontal run is allowed on rear vented applications , though the addition of a 45° elbow is permitted for corner installations. REAR VENTING NOT PERMITTED FOR 4/7 VENTING. 18'' Max. horozontal PXT20 Extention run with no vertical lift Heat Sheild Termination... -
Page 13: Section 3-2: Installing A Roof Mounted Direct Vent Termination
Installation Section 3-2: Installing a Roof Mounted Direct Vent Termination Roof mounted terminations This section applies to installations where the direct vent termination will be roof mounted. The following details are some possible configurations for roof mounted terminations. See below. Section 3-2-1: Venting Layout PVTK1 PVTK1... -
Page 14: Section 3-3: Installing A Wall Mounted Termination
NOTE: If subject to a highly corrosive environment A Termination with a MOSR Frame is installed from the inside of the i.e. Seaside, Montigo recommends using Stainless Steel Termination. structure. These are commonly used in high-rise construction. -
Page 15: Section 3-1: Converting Top/Rear Vent
• Install the (removed) rear flue cover and gasket material, to the Top • Montigo recommends the use of a flex section for the first section of vent outlet. Fasten the cover with included hardware. venting connected directly to the fireplace, offering greater flexibility •... -
Page 16: Section 3-3-2.2: Alternate Venting Components 5"/8
Installation Section 3-3-2.2: Alternate Venting Components 5"/8" The following components are approved for use with Montigo products. Please contact your local Montigo dealer for further information. Component Simpson Duravent MetalFab Selkirk Flexmaster Montigo Part Number Part Number Part Number Part Number... -
Page 17: Section 3-3-2.2: Alternate Venting Components 4"/7" (For Reduced Drsq38 Units)
Installation Section 3-3-2.2: Alternate Venting Components 4"/7" (For reduced DRSQ38 units) The following venting components are approved for use with Montigo products. Please contact your local Montigo dealer for further information. Component Montigo Part Number Simpson Duravent Part Number Flexmaster Part Number Termination MTO4 (3" Length) 46DVA-HC MTO4F (3"... -
Page 18: Section 3-3-3: Heat Shields
Installation Section 3-3-3: Heat Shields Installing the included heat shield Installing a Wall Mounted Heat shield The included Heat shield CANNOT be used WITHIN 36" horizontal or The RHS10* Heat shield must be used if vent pipe passes through a 60"... -
Page 19: Section 4: Wiring
DRSQC38LI Installation of the wall switch Montigo supplies 15' of low voltage wire to be plugged into the control board. Connect to a standard single pole ON/OFF switch to the location of your choice. You may extend these wires up to 30' in length with a wire of equal quality. -
Page 20: Drsq (N/L) I-2 Wiring Diagram
Installation DRSQ (N/L) I-2 Wiring Diagram BATTERY BATTERY PACK PACK 1.5V AA type 1.5V AA TYPE 1.5V AA type 1.5V AA type 1.5V AA TYPE 1.5V AA type SPARK SPARK GREEN GREEN 1.5V AA TYPE 1.5V AA type 1.5V AA type MAIN Power MAIN WHITE... -
Page 21: Section 5: Installing The Gas Line
N.P.T. plug to be fitted with a hose barb. unit or worse, a gas leak. • Montigo requires a service shut off valve be located in an accessible location to isolate the gas supply. • Only install gas shut-off valves approved for use by the state, province, or other governing body in which the fireplace is being installed. -
Page 22: Section 6: Finishing
Installation Section 6: Finishing Finishing Around the Fireplace Sidewall clearances Fireplace Facing Side wall clearances are 4". Combustible surrounds may be installed with 4" clearance to the side of the fireplace as shown. When sizing the finish material for your fireplace, it is important to remember the following: THE OPENING MUST NOT BE OBSTRUCTED IN ANY WAY - to do so restricts the air supply for the control compartments and it also prevents access for servicing controls. -
Page 23: Elevated Surface Temperatures
Installation Elevated surface temperatures The below are surface temperatures of the area above the fireplace opening after a 3 hour burn period. Use this guide in good faith to decide on an appropriate facing material and mantle. A cool wall kit can aid in lowering surface temperatures as shown. Tests are based off a 24,000 BTU NG unit. -
Page 24: Section 8: Removing & Installing The Screen / Door
Installation Section 8: Removing & Installing the Screen / Door Removing the Screen Removing the door Follow the steps below to remove, or install the fireplace screen and The door is removed in a few simple steps. Follow these steps below door. Before beginning any screen or glass removal, make sure that the to unlatch the door buckles and remove the door. -
Page 25: Propane Conversion
Installation Propane Conversion Tools required To convert the DelRay from 1. Shut off gas supply. Natural Gas to Propane, install the GCA020 / GCA021 1). Torx T20 Screw Driver Bit conversion kit. The unit must 2. Remove the 2 screws securing the pilot cover to the media tray. 2). - Page 26 Installation 6. Use screwdriver to carefully detach spring clip from the pilot 10. If necessary, pilot flame size can be adjusted using a flathead hood. screwdriver to adjust “pilADJ” screw shown Figure 13.g Adjust pilot size Figure 13.d Removing the spring clip 7.
-
Page 27: Section 9: Installing The Accessories
Installation Section 9: Installing the Accessories The DelRay Square transitional burner The burner for the DelRay Square has been developed in away that equally supports contemporary and traditional scenes without the need for a burner swap. Installing glass media Optional fireglass may be purchased from the dealer. Remove the Door as shown in the previous Instruction. -
Page 28: Traditional Logset Installation
Installation Traditional Logset Installation Step 1: Log A is placed at the rear center of the media tray Step 5: Log E is placed diagonally directly in front of log A Step 2: Log B is placed at the left corner of the firebox, with the charred Step 6: Rest log F on logs E and D end resting on log A Step 3: Place log C behind the pilot with the charred end wrapping... - Page 29 WARNING: This appliance is intended for use only with the included chips on top of the burner tray. Care should be taken when placing the Montigo burners and accessories. Never install or add any additional embers, as blocked burner ports may cause an incorrect flame pattern, or alternative media, rock wool or other material in this appliance.
-
Page 30: Birch Logset Installation
WARNING: This appliance is intended for use only with the included Only cover the burner with one layer of coals. Arrange the ember chips Montigo burners and accessories. Never install or add any additional on top of the burner tray. DO NOT cover the pilot with logs. -
Page 31: Driftwood Logset Installation
WARNING: This appliance is intended for use only with the included Only cover the burner with one layer of coals. Arrange the ember chips Montigo burners and accessories. Never install or add any additional on top of the burner tray. DO NOT cover the pilot with logs. -
Page 32: Black Reflective Glass
Installation NOTICE Panels should be handled with gloves, oils from the skin will permanently stain glass Black Reflective Glass Step 4: Bend the left side tab on the bracket. Place right side glass in place, and secure with the bracket using screw Before beginning any install, make sure that the unit has not been in Bend the right side tab on the bracket. -
Page 33: Brick Liner Install
Installation Brick Liner Install Step 3: Use the included clips to secure right panel into the screw hole referenced in step 1. Before beginning any install, make sure that the unit has not been in operation and that it is at room temperature. Step 1: Remove the two screws on each side where the brackets will go in Figure 20.b Remove the two screws Figure 20.b Secure with the bracket using screw... - Page 34 Operation DANGER HOT GLASS WILL CAUSE BURNS. DO NOT TOUCH GLASS UNTIL COOLED. NEVER ALLOW CHILDREN TO TOUCH GLASS. A barrier designed to reduce the risk of burns from the hot viewing glass is provided with this appliance and must be installed for the protection of children and other at-risk individuals.
-
Page 35: Section 10: Cleaning And Maintenance
Operation Section 10: Cleaning and Maintenance General Pilot Burner Adjustment. • Have the fireplace and installation inspected yearly. The inspection 1. Locate Pilot Adjustment Screw. (See figure 28) must include, but is not limited to, the following: 2. Adjust pilot screw to provide properly sized flame as shown. •... -
Page 36: Indoor Fireplace In Protected Outdoor Applications
Appendix Indoor fireplace in protected outdoor applications This fireplace may be installed into outdoor locations provided they are suitably protected from direct water impingement. However, all installation clearances in the appliance manual must be observed. Framing, Clearances to Combustibles, Mantel Heights, Facing Requirements, Venting Installation, etc. -
Page 37: Appendix A: Venting Terminations
Appendix Appendix A: Venting Terminations Covered Covered Alcove Detail Alcove Detail Vinyl Siding 2’ 2’ 2’ 2’ 17.5’’ 29.5’’ 11.5’’ 17’’ Must use Vinyl Siding Termination Shield Location Canada* USA** clearance to the termination frame above grade, veranda, porch, deck, or balcony 12 inches 12 inches clearance to top of doors or operable windows... -
Page 38: Appendix B: Warranty
(collectively referred to herein as "The Companies"), warrants the If the components of the appliance covered by this warranty Montigo gas appliance (referred to herein as 'the appliance') to are found to be defective within the time frame stated (see The... -
Page 39: Appendix B: Warranty Continued
Montigo dealer (www.Montigo.com) or contact Montigo direct at techsupport@ montigo.com. Ensure you have your sales receipt and the model and serial number of your appliance. DO NOT ATTEMPT TO DO ANY SERVICE WORK YOURSELF If you cannot locate the installing dealer, or nearest dealer/ distributor, you must notify The Companies in writing. -
Page 40: Appendix C: Amendment
Appendix Appendix C: Amendment (Gas Fireplace / Equipment sold in the State of Massachusetts) 5.08: Modifications to NFPA-54, Chapter 10 (1) Revise NFPA-54 section 10.5.4.2 by adding a second exception as 4. INSPECTION. The state or local gas inspector of the side wall follows: horizontally vented gas fueled equipment shall not approve the installation unless, upon inspection, the inspector observes... - Page 41 Notes XG0230 - 052020...
- Page 42 Installation & Maintenance Manual DelRay Square Single Sided Gas Fireplace XG0230 - 052020...
