Final Installation Steps - Dynojet POWER COMMANDER III Installation Instruction

PCIII connector
PCIII harness
Grey wire/Posi-Tap
Ground wire
from PCIII
i729-411 www.powercommander.com
Stock connector
TPS
12 Plug the ORANGE colored wires from the
PCIII in-line of the front injector and stock
wiring harness (Fig. H).
13 Remove the right hand fairing.
14 Route the PCIII harness along the right
hand side frame down tube. Use the
existing wraps to hold the PCIII harness in
place (Fig. J).
15 Locate the Throttle
Position Sensor
on the right hand
side of the throttle
bodies.
17 Connect the GREY
wire from the PCIII
to the Posi-Tap.
18 Attach the ground wire from the PCIII to
the right hand engine cover bolt shown in
Figure K
19 Reinstall the right hand fairing
2007 Ducati 1098 - PCIII USB - 4
