2003 Triumph Daytona 600
Parts List
1
Power Commander
1
USB Cable
1
CD-ROM
1
Installation Guide
1
Power Adapter
2
Power Commander Decals
2
Dynojet Decals
1
Velcro
Strip
®
1
Alcohol Swab
The ignition must be turned off before installation.
After turning off the ignition make sure not to dis-
connect anything for at least one minute. If some-
thing is disconnected while the CDI is powering
down a check engine light may be indicated. Also
do not turn on the ignition while one of the electri-
cal connectors is unplugged. If a check engine
light is indicated the code can only be cleared by
a Triumph dealer.
You can also download the Power
Commander software and latest maps
from our web site at:
www.powercommander.com
PLEASE READ ALL DIRECTIONS BEFORE STARTING INSTALLATION
Dynojet Research 2191 Mendenhall Drive North Las Vegas, NV 89031 (800) 992-4993 www.powercommander.com
i509-411
Installation Instructions
Button Adjustment Display
Faceplate Buttons
Expansion Port
USB Port
2003 Triumph Daytona 600 - PCIII USB - 1
Advertisement
Table of Contents
Related Manuals for Dynojet POWER COMMANDER III
Summary of Contents for Dynojet POWER COMMANDER III
- Page 1 Commander software and latest maps from our web site at: www.powercommander.com PLEASE READ ALL DIRECTIONS BEFORE STARTING INSTALLATION Dynojet Research 2191 Mendenhall Drive North Las Vegas, NV 89031 (800) 992-4993 www.powercommander.com i509-411 2003 Triumph Daytona 600 - PCIII USB - 1...
- Page 2 Remove the seat. Remove the fuel tank Unplug this connector Note: The fuel tank does not need to be removed to perform the install but it will make it easier. Unplug the connector from the throttle bodies to the wiring har- ness (Fig.
- Page 3 Install the Power Commander in the tail section. Make sure to use the supplied alcohol swab to clean the inner rear fender before attaching the Power Commander. Use the supplied velcro to secure the unit to the inner rear fender (Fig. D). i509-411 www.powercommander.com 2003 Triumph Daytona 600 - PCIII USB - 3...
