1998-1999 Suzuki GSXR750
Parts List
1
Power Commander
1
USB Cable
1
Installation Guide
1
Power Adapter
2
Power Commander Decals
2
Dynojet Decals
Velcro ® Strip
2
1
Alcohol Swab
The ignition MUST be turned
OFF before installation!
You can also download the Power
Commander software and latest maps
from our web site at:
www.powercommander.com
PLEASE READ ALL DIRECTIONS BEFORE STARTING INSTALLATION
Dynojet Research 2191 Mendenhall Drive North Las Vegas, NV 89081 (800) 992-4993 www.powercommander.com
i302-411
www.powercommander.com
Installation Instructions
Button Adjustment Display
Faceplate Buttons
Expansion Port
USB Port
1998-1999 Suzuki GSXR750 - PCIII USB - 1
Advertisement
Table of Contents
Related Manuals for Dynojet power commander III
Summary of Contents for Dynojet power commander III
- Page 1 Commander software and latest maps from our web site at: www.powercommander.com PLEASE READ ALL DIRECTIONS BEFORE STARTING INSTALLATION Dynojet Research 2191 Mendenhall Drive North Las Vegas, NV 89081 (800) 992-4993 www.powercommander.com i302-411 www.powercommander.com 1998-1999 Suzuki GSXR750 - PCIII USB - 1...
- Page 2 Remove the main seat and the passenger seat. Hold the front of the fuel tank PCIII harness up using the prop rod located in the trunk area. Lay the PCIII in the tail section. Route the PCIII harness under the subframe and go towards the front of the bike.
- Page 3 Locate and unplug the stock wir- ing harness from the Throttle Position Sensor on the right hand side of the throttle bodies. Plug the Power Commadner in-line of the Throttle Position Sensor and the stock wiring harness (Fig. D). Attach the ground wire from the PCIII to the negative side of the battery (Fig.
