18 : 2.Initialize as End Product

On this chapter we will give birth to the custom model, which represents your finished product (speaker, rack amp) that you
aim to manage using ArmoníaPlus™. In fact, we will create a software plugin so that the ArmoníaPlus™ is able to accept and
to recognize your custom model as it was defined.
1. Open ProManager Plus™
2. Click on the DSP Initializer button
3. Discover the DSP-4 using selected Com port as
shown previously and press Next
4. Select Custom Model
5. Select the model you have created during earlier
stages
6. Specify the product serial assigned to your system/
model
7. Choose a firmware version to be stored on your DSP
or tip the Skip firmware update check box
8. Press Start and wait until the DSP is successfully
initialized. At the end of initialization, device will be ready to
be recognized by Plugin previously installed.
40 | IpalMod | User guide
Inizialize as End Product
