powersoft D-Cell504 Technical Note

TECHNICAL NOTE #15 rev. 01
Energy save mode
How to have Energy Save mode manually activated

1 Preliminary consideration

This article is related to the following products:
f D-Cell504
f D-Cell504 IS

2 Procedure

There are two methods to obtain the same result.

1.1 Method #1

You have to ground pin 16 on the CN1 connector, as shown in
FIGURE 1.

1.2 Method #2

You have to ground J1003 on the interface board, as shown in
FIGURE 2.
© 2012 - 2013 Powersoft
powersoft_TN015_EnergySave_en_v1.0
FIGURE 1: Grounding Pin 16 on CN1 Connector
FIGURE 2: Grounding J1003 on the interface board
Keep This Technical Note For Future Reference
