Installation
Warning: All procedures and methods used in the installation of the cabinet must comply
with all applicable federal, state, county, and local laws, regulations, ordinances and
codes. This includes compliance to all applicable Occupational Safety and Health
Administration (OSHA) and Environmental Protection Agency (EPA) regulations when
dealing with hazardous materials and work place hazards. Compliance of these
requirements is the responsibility of the installer and the site management.
Caution: Water seepage: When drilling holes in a basement or below-ground structures,
ensure that you do not penetrate through the concrete and into the vapor barrier. If this
does occur, groundwater may come up through the anchor hole. It is the customer's
responsibility to verify building construction features before the drilling operation begins.

Marking Floor Layout for Cabinet Installation

Cabinet layout is site specific. The recommended minimum aisle spacing is 3 ft. (91.5 cm) front and
rear.
Warning: When planning the location of the equipment, avoid positioning the equipment
over permanent gas, water, electrical utility lines or conduits.
Caution: Restricted available workspace: In a raised-floor application, ensure that
Cabinets are positioned with enough clearance to allow you to remove tiles.
Recommended Materials
• Safety glasses
• Chalk-line, with chalk
• Fiberglass tape measure
• Felt tip pen
• Isolation sheet (template in Raised Floor Kit) to mount one cabinet
Procedure How to Mark the Floor Layout
Use the following procedure to mark the floor layout.
1. Verify with a customer representative that the required area dimensions and equipment location
correspond with the marked floor plan.
2. Use the floor plan provided with the engineering site file specifications to mark the front base line
and the borders of the cabinet with the chalk line.
3. Align the front of the cabinet template (isolator pad) along the front chalk line. Using a felt tip pen,
mark anchor locations in the middle of each oval anchor slot, see
910-5681-001 Revision E, February 2014
Cabinet Installation
Figure 23: Mark Floor Layout.
