7.8.1.10.2 "Static Routes" Group

Each configured static route has its own area in the display.
To maintain compatibility with earlier firmware versions, at least two routing
entries always exist. These can be disabled, but not removed. If a route is either
removed or disabled, it is no longer entered in the system.
Table 64: WBM "Routing" Page – "Static Routes" Group
Parameter
Enabled
Destination Address
Destination Mask
Gateway Address
Gateway Metric
Click the [Submit] button to apply the changes. The changes take effect
immediately.
To add a new route, click the [Add] button. The change takes effect immediately.
Click the [Delete] button to delete an existing route. The change takes effect
immediately.
Explanation
Specify here whether the selected route should be
used.
Disabled The route is not used.
Enabled The route is used.
Specify here whether any network devices or only a
specific network device or device pool should be
accessible.
Any network devices can be
default
reached.
Only a specific network device
Network address or device from the specified
address pool can be reached.
Enter the subnet mask of the device here.
If "default" is entered for Destination Address, the
value "0.0.0.0" must be entered here.
Enter the address of the gateway here.
Set the number used as the metric here.
When there are multiple routes with the same
destination address and destination mask, the
metric specifies the gateway to which network data
packets are first sent. Priority is given to routes with
a lower value for the metric. The default value for
the metric is 20.
The lowest value is 0.
The highest value is 2³²−1 = 4,294,967,295.
Version 1.0.0, valid from FW version 03.01.07(13)
