6.2.1.

Establishing a WLAN connection

Connect power to the idOil control unit.
The display presents the message shown in
the figure: NO SENSORS.
Press the reset button briefly.
A symbol indicating a WLAN network
connection is shown in the upper left corner
of the display.
If the device power is already on, press the
reset button twice; the first push activates
the backlight and the second press activates
the WLAN connection.
Establish a WLAN connection between the idOil control unit and terminal device as
follows:
1. Use the network settings of the terminal device to find the WLAN network provided by
the idOil device.
2. Enter the WLAN network password. The password is five zeroes followed by the eight
final characters of the device's serial number. The serial number can be found in the
idOil device's type plate.
If the serial number is 8540564_1112118J, for example, the WLAN password is
000001112118J.
3. Open the web browser of your terminal device and enter the IP address: 192.168.0.1.
A connection has now been formed between the terminal device and the idOil control unit.
The following sections detail the measures required in connection to initial use.
Figure 21. WLAN network on
