Installation and Operating Instructions | idOil Solar
7.2.

Resetting an alarm

An alarm can be reset by pressing the test button in the cover.
Resetting an alarm deactivates the buzzer. However, the buzzer is always reactivated for 10
s every 24 hours until the cause for the alarm is eliminated.
The relays do not change their state when an alarm is reset with the reset button.
7.3.

Using the browser-based user interface

The following sections describe the use of the idOil browser-based user interface.
The process of establishing a connection to the browser-based interface is described in the
section Commissioning through the browser-based interface.
7.3.1.

Home screen

The browser-based interface always starts in the home screen shown in the figure below.
You can also access the home screen by pressing the
Figure 27. Home screen
The items listed in the following table are shown in the home screen. The menus are
described in more detail in the sections below.
icon in the upper left corner.
