10.

Appendices

10.1. Factory settings for idOil Solar

Every idOil Solar alarm unit has the following settings pre-defined in the factory.
The Low power settings of idOil Solar can be changed from idOil-30 Control Unit's
settings either through the web user interface or by text messages:
Beacon light adjustment:
Measuring interval:
Display Backlight blinking during alarm (factory setting ON)
Battery voltage monitoring:
Most of the factory settings can also be set by text messages.
Command
parameters
DI 1:
1: Oil level sensor.
2: High liguid sensor.
3: Sludge level sensor.
VLIM 11.4
MI 10
LI 12
More information about the format of each command and parameter can be found from the
following documents:
idOil-30 Battery, Installation and Operating Instructions (DOC001699).
idOil-30 Battery 3G, SMS-messages - Commissioning and use (DOC001696).
Repeat time (factory setting 10 s)
Duration (factory setting 600 ms)
Beacon connected to relay 1 or relay 2 (factory setting off)
Repeat (factory setting 10 min)
Start delay (factory setting 5 s)
current battery voltage level
Monitoring (factory setting ON)
Battery low voltage alarm (factory setting 11,4 V)
and
Explanation
Command sets probe names as follows:
Probe nbr 1 is identified as "Oil level sensor".
Probe nbr 2 is identified as "High liquid sensor".
Probe nbr 3 is identified as "Sludge level sensor" .
Alarm level (in Volts) for minimum battery voltage.
Measuring interval
idOil Solar wakes up every 10 minutes for 20 seconds from
low-power mode to check the status of probes.
Listening interval (hours)
idOil Solar wakes up from normal (low-power) mode every 12
hours (starting from the time idOil is put to low-power mode)
for 2 minutes to check if users have given new SMS
commands, and to answer them.
