To Configure the PMC Stream for Listen-in (PMC Broadcaster):
1. Ensure the VIPA device used to provide the listen-in audio stream has been configured with correct IP
address and all required Audio Devices, including audio inputs and outputs.
Example:
The iPAM400 in Figure 17 (page 53) has two Audio Device nodes.
Each Audio Device node has two Audio Input nodes and two Audio Output nodes.
2. Select the required Audio Device node, and ensure all parameters have the system default settings.
Refer to the System Design documentation to find out the audio input used for the listen-in function.
Example:
Audio Input 2 is used for listen-in using PMC Broadcaster method in Figure 16 (page 52).
Therefore, Audio Device Built-in Sound (Inputs 1 & 2, Outputs 1 & 3) is selected.
3. Select the Audio Input used for listen-in function and set the configuration parameters as follows.
•
Enable (Required Settings): Enable the input.
•
Audio Groups (Advanced Optional Settings): Assign a user-defined audio group.
Example:
Audio group "ipam02-stream3" has been assigned to Audio Input 2.
•
Other parameters: System default settings. Adjust audio level as required.
4. Add a PMC Device node to the VIPA device node.
Refer to the System Design documentation to find out the multicast address and port used for the
listen-in provided by this audio input.
•
Port: Communication port assigned to the listen-in stream associated with this zone;
From the microphone configuration file; see button 8 in Figure 1 (page 14):
Port = port
Example: Port = 17041
•
Multicast address: Multicast address assigned to the listen-in stream associated with this
zone
From the microphone configuration file; see button 8 in Figure 1 (page 14):
Multicast address = ipaddr
Example: Multicast address = 239.0.2.41
•
Other parameters: system default settings
5. Add a PMC Output to the PMC Device of the VIPA device node.
•
Type: Static
•
Audio Groups (Advanced Optional Settings): The audio group assigned to the Audio Input
Example: Audio Groups = "ipam02-stream3"
6. Configure the required MPS microphone buttons for type "listen-in"; see Section "5.1 Configuring a
MPS Microphone with IP Connection" (page 38).
7. Ensure that the microphone buttons used for listen-in are configured in the microphone's XML
configuration file; see Section "3 MPS Microphone Configuration" (page 11).
