5.1

Configuring a MPS Microphone with IP Connection

Figure 7 MPS microphone configuration – IP connection (example using iPAM400)
NOTE:
To display the attributes and values on the left side panel, select View>Enable Show Attributes.
MPS-Series – Configuration Guide
VIPA Device hosting the MPS microphone
Microphone node:
•
Audio Group: <Live audio PMC address>:<Live audio PMC port>:1
•
Control Port: JOUL:<Microphone IP address>:<VIPA device IP address>:<Port>
•
Other parameters: as required
