MPS Microphone Configuration

The MPS microphone's configuration file is in XML format. The configuration file is downloaded into the MPS
microphone using the microphone Configuration Tool.
IMPORTANT:
1) The microphone IP settings and audio levels are configurable from the microphone's LCD display menu.
Refer to the Quick Operation Guide for details.
2) The microphone's XML file configuration is required if:
•
The microphone buttons are to be accessed from the LCD display menu
•
The microphone is connected over an IP network to a host VIPA device, and the listen-in and/or the
background music function is used
•
Your system requires the microphone to operate in fallback mode when the microphone is unable to
communicate to its host VIPA device over the IP network or when the microphone is a stand-alone
unit in an IP network
3) Users must have basic knowledge of XML in order to modify the microphone configuration file.
4) The configuration attribute and attribute values described in Table 3 (page 15) are correct for the current
MPS microphone software version at the time of publication (V1.5.6).
To Modify the Microphone Configuration:
1. Back up the current configuration file before you make any changes.
2. Open the configuration file using an XML editor; see example in Figure 1 (page 14)
3. Modify the required attribute; refer to Table 3 (page 15).
4. Save the changes.
5. Validate the XML file in a known source (e.g. Firefox) before deployment.
