ASL INTERCOM MPS Series Configuration Manual page 17

MPS Microphone Software Version 1.5.13
Attributes
live-port
bgm-addr
bgm-port
chime
str-fwd
max-call-time
partial-grant
partial-loss
route-no-zones
preserve-
zones
ptt-all-call
audio-params
routing-params
button-cfg
MPS-Series – Configuration Guide
Description
Communication port used for
live announcements
Multicast address used for
background music
Address range:
239.xxx.xxx.xxx
Communication port used for
background music
Chime tone played before a
live announcements
Enables/disables the
Store&Forward function (for
future development)
Not currently used
Fallback mode (LOCAL
CONTROL) only: Determines
whether partial grant of routes
is allowed
Fallback mode (LOCAL
CONTROL) only: Determines
whether an overridden route is
reinstated when override is
removed during the original
announcement
For future development
Fallback mode (LOCAL
CONTROL) only: Determines
whether the TTT button is to
store the last zone selections
Fallback mode (LOCAL
CONTROL) only:
Enables/disables the All Call
facility for the TTT button
default Determines whether
parameter values defined in
the "default-audio-params"
section are to be used
default Determines whether
parameter values defined in
the ""default-routing-params"
section are to be used
button-number Button number
name Button name displayed on the
LCD display
U-0664-0265.doc – Issue: 03 complete, approved
Attribute Values
As configured on the host VIPA device (VIPA
device configuration: Microphone> Audio Group);
see Section 5.1 (page 38).
LCD Display: IP SETTINGS>PMC LIVE PORT
As configured on the host VIPA device (System
configuration: Linutop>PMC Device); see
Section 5.2 (page 45).
LCD Display: IP SETTINGS>PMC BGM
ADDRES
As configured on the host VIPA device (System
configuration: Linutop>PMC Device); see
Section 5.2 (page 45).
LCD Display: IP SETTINGS>PMC BGM PORT
Available chime types: "none"
At the time of publication, the chime is configured
on the VIPA device which is hosting the
microphone.
"false" (Do not change!)
"60"
"true" (default) or "false"
NOTE: The partial grant permission is hard-
coded and set to "true".
"true" (default) or "false"
NOTE: The partial loss permission is hard-coded
and set to "false".
"true" (Do not change!)
As required:
•
"true": The TTT button stores the last
selection.
•
"false" (default): The TTT button does not
stores the last selection.
As required:
•
"true": The TTT button acts as an All Call
button when pressed without a prior zone
selection.
•
"false: The TTT button acts as a Push To
Talk button on zones selected by other
buttons or LCD display menu.
"true" (Do not change!)
"true" (Do not change!)
"1" to "50" (as required)
Refer to Section "3.1 Microphone Button
Capability" (page 12) for supported button types.
Up to 14 alphanumeric characters (as required).
CAPITAL letters recommended.
Page 17 of 60
