ASL INTERCOM MPS Series Configuration Manual page 18

MPS Microphone Software Version 1.5.13
Attributes
NOTES:
Fallback mode is also known as backup or stand-alone mode.
MPS-Series – Configuration Guide
Description
type Button type
zones Zones addressed when the
microphone is operating in
fallback mode (LOCAL
CONTROL).
Only for "zone-select" type
button.
ipaddr Multicast address used for
listen-in (Only for "listen-in"
type button)
port Communication port (only for
"listen-in" type button)
U-0664-0265.doc – Issue: 03 complete, approved
Attribute Values
Available button types (as required):
For Router connection:
•
"zone-select": zone select button for live
announcements or message routing
For IP connection:
•
"zone-select": zone select button for live
announcements
•
"bgm": Music ON/OFF button
•
"listen-in": Listen-in ON/OFF button
As required.
Comma separated (no space) list of zone names
as defined in the "destination-zones" section
above.
If the button is not used in fallback mode, then a
dummy zone name (or space) must be defined;
see buttons 11 and 12 in Figure 1 (page 14).
As configured on the VIPA device providing the
listen-in multicast broadcast
As configured on the VIPA device providing the
listen-in multicast broadcast
Page 18 of 60
