MPS-Series – Configuration Guide
Figure 10
MPS fault reporting – IP connection: Fault tree (example using iPAM400)
VIPA Device hosting the MPS microphone
Faults of a MPS microphone connected over IP are
reported to the last analogue audio input.
In this example, MPS faults are reported to Input Port 6.
A communication failure is present.
U-0664-0265.doc – Issue: 03 complete, approved
Page 44 of 60
