Attributes
default-mic ipaddr
port
destination- zone
zones
mic-unit type
Name
unit-id
ip-address
ip-port
live-addr
MPS-Series – Configuration Guide
Description
ip-gain-dmic Microphone input gain
ip-gain-emic Headset boom input gain
ip-gain-listen Listen-in input gain (from
Router)
ip-gain-expand Audio input gain (expansion
module, for future
development)
Default IP address on a
microphone out of the box
Communication port
name Destination zone name used in
the button configuration below.
This zone is only addressed
when the microphone is
operating in fallback mode
(LOCAL CONTROL).
output Identification of the VIPA
device that is addressed by
the MPS microphone when it
is operating in fallback mode
(LOCAL CONTROL).
A live announcement will be
broadcast to all zones
addressable by the destination
VIPA device when the
microphone is operating in
fallback mode. Currently it is
not possible to address
individual zones in fallback
mode.
Microphone type
Microphone name displayed
on the Config Tool
Microphone unit identification
Microphone IP address
Communication port
Multicast address used for live
announcements
Address range:
•
239.xxx.xxx.xxx for
general use
•
239.0.0.xxx for fallback
mode operation
U-0664-0265.doc – Issue: 03 complete, approved
Attribute Values
"0" (minimum level – 0%) to "120" (maximum
level – 100%)
Default: "30" (25%)
LCD display: AUDIO LEVELS>MICROPHONE
"30" (Do not change!)
"30" (Do not change!)
"30" (Do not change!)
"172.16.3.35" (as required to be in the same
subnet as the host PC)
"15256" (Do not change!)
Alphanumeric (as required)
Must have the following format:
"03NN0001"
Where NN is obtained from the destination VIPA
device configuration. NN is the hexadecimal
value of the "Suffix" configured for
"rctransactionless-router-d" RC script; see
Section 5.4 (page 58).
NOTE: The configuration of the "Run announce-
d" property of the VIPA device will determine the
zones addressed by the MPS microphone in
fallback mode:
•
"Global": all zones allocated to an audio
output (local or remote)
•
"Local": all local zones
•
"No": no zones
"desk" (Do not change!)
Alphanumeric (as required)
3 digits (as required)
NOTE: Must match the last octet of the "live-
addr". Otherwise, the microphone will not operate
in fallback mode.
As configured on the host VIPA device (VIPA
device configuration: Microphone>Control Port);
see Section 5.1 (page 38).
LCD Display: IP SETTINGS>UNIT IP ADDRESS
"15256" (as required)
LCD Display: IP SETTINGS>UNIT IP PORT
As configured on the host VIPA device (VIPA
device configuration: Microphone>Audio Group);
see Section 5.1 (page 38).
LCD Display: IP SETTINGS>PMC LIVE
ADDRES
NOTE: The last octet MUST match the "unit-id"
defined above. Otherwise, the microphone will
not operate in fallback mode.
