4.6.4

Play DVA Button (DAU, VAR8, ACU and VAR8-ACU only)

Menu: Config System Router Inputs Mic/Line <I/P #n – name> Paging Microphone>
The button function is 'play DVA to selected outputs'. When the button is pressed a route is made connecting
a DVA audio source from the Slave Unit or the Audio Control Unit (ACU) to outputs which have been pre-
selected using buttons configured for zone selection.
The 'Play DVA' button can be considered a variant of the 'DVA Routing' button, which routes only one DVA
audio source, and requires the zones to be pre-selected using Zone Select buttons.
Configure a button for 'Play DVA', and then configure the following parameters.
4.6.4.1

DVA Message

Menu: Config System Router Inputs Mic/Line <I/P #n – name> Paging Microphone>
The DVA source can be from the:
•
Audio Control Unit (ACU):
The ACU's DVA will be played over the network to selected zones.
•
Slave Unit in the Intellevac Network:
The local DVA will be played to selected zones.
Select the DVA audio source that will be played to the selected zones.
Consult the system design documentation for which DVA input is under the control of this button.
4.6.4.2

Trigger Mode

Refer to Section "4.6.8.1 Trigger Mode" (page 35).
4.6.4.3

DVA Play Mode

Refer to Section "4.6.8.2 DVA Play Mode" (page 36).
4.6.4.4

Busy Indication Mode

Refer to Section "4.6.8.3 Busy Indication Mode" (page 36).
MPS-Series – Configuration Guide
Buttons Zoning <Button # nn> Play DVA Select DVA
NETWORK IP
SLAVE IP
U-0664-0265.doc – Issue: 03 complete, approved
Page 33 of 60
Buttons Zoning <Button # nn> Play DVA
