Tandberg Data Magnum 448 Manual page 6

Half height
tape drive
Tape drive
carrier
Route cable
through tape
drive carrier
Figure 6 Rev "A" power cable routing—half height tape drives
Half height
tape drive
Tape drive
carrier
Route cable
outside
tape drive
carriers
Figure 7 Rev "B" power cable routing—half height tape drives
6 16
OF
Library
Library
Rev "A" power cable
Top power connector
(not used)
Important!
Third power
Installing a third (or third and
connector (not used)
fourth) LTO-3 half height tape
drive requires a Rev "B" power
Second power
supply.
connector
See
Bottom power
Supply" on page
connector
Rev "B" power cable
Top power connector
(short cable)
Bottom power connector
(short cable)
Top power connector
(long cable)
Bottom power connector
(long cable)
"Revision "B" Power
4.
