This applies to both SCSI and Fibre Channel library configurations.
R T
EPLACING A APE
!
Important
To replace a tape drive with a different tape drive of the same configuration (half height to half height, or full
height to full height), follow these steps.
1. Preparing for replacement—
a. Update library firmware to v. V1D181 or higher (see Important note above).
b. Power off the host.
c. Power off the library (press the 0 on the back of the unit).
d. Disconnect the power cord, the SCSI or Fibre Channel cable(s), and the terminator (if present).
e. Remove the tape drive cover plate. Set the plate and the screws aside.
Figure 14 Tape drive cover plate (FH SCSI library)
If your library has...
Tape drive configuration
Full height
Half height
D (
RIVE SAME CONFIGURATION
You must update your Magnum 448 library to the current firmware (v. V1D181 or
higher) before you install your new drive. The firmware allows the library to
auto-configure the tape drive installation upon power up, eliminating the step of
manually configuring the library after tape drive installation.
If your library code is not updated to v. V1D181 or higher, you will need to contact
Tandberg Data technical support for manual configuration instructions.
Back of library
Attach this SCSI cover plate...
Quantity Location
Two None
One Top
Four None
Three Top
Two Top and third
One Top three
)
External drive label
None
a
Drive 2
None
Drive 4
Drive 4 and 3
Drive 4, 3, and 2
Screws
(4 each side)
Tape drive cover plate
0
Power OFF (press the )
Disconnect power cord
