Tape drive (HH configuration)—– Connect the supplied serial cable and the power cable to the tape drives.
Figure 12 Installing additional tape drives: half height serial connectors
either
Your library has
Rev "A" or Rev "B" power
See Figure 3.
cable.
Rev "A" power cable
Route Rev "A" power
through
cable tape drive
carriers, as shown here
Rev "B" power cable
Route Rev "B" power
outside
cable tape drive
carriers, as shown here
Important!
Installing a third (or third and
fourth) LTO-3 half height tape
drive requires a Rev "B" power
supply.
See "Revision "B" Power
Supply" on page 4.
Figure 13 Installing additional tape drives: half height power connectors
d. Slide the tape drive the remaining distance into the library. Install the tape drives from bottom to top—fill
the bottom slot first, the second slot next, and so forth. Do not skip slots. Continue adding tape drives, as
needed.
4. Completing the installation—
a. Locate the tape drive cover plate (see
the necessary SCSI plates, then attach the tape drive cover plate with the screws you removed earlier.
!
Important
10 16
OF
Library
a
Library
"Tape Drive Cover Plates" on page 3
The library requires both the SCSI cover plates and the tape drive cover plates for
ESD protection. Do not leave any openings uncovered.
Library
Serial cable connections
Half height configuration
Also see Figure
Drive 4
Top serial connector
Drive 3
Third serial connector
Drive 2
Second serial connector
Drive 1
Bottom serial connector
Power cable connections
Half height configuration
Top power connector
Third power connector
Second power connector
Bottom power connector
Top connector (short cable)
Bottom connector (short cable)
Top connector (long cable)
Bottom connector (long cable)
and Figure 14
1.
below). Remove
