4. Completing the installation—
a. Attach the SCSI cover plates and the tape drive cover plate that came with your replacement kit. See
Drive Cover Plates" on page 3
If your library has...
Tape drive configuration
Full height
a
This applies to both SCSI and Fibre Channel library configurations.
!
Important
R O
ESUMING PERATION
1. Power the library off (press the 0 on the back of the unit).
2. Connect the interface cables.
Connect the Fibre Channel cable (or cables if you installed more than one Fibre Channel tape drive).
or...
Connect the SCSI cable (or cables if you installed more than one tape drive) and a terminator (if needed).
!
Both LTO-2 and LTO-3 tape drives require an Ultra 3 or LVD 160 terminator to function
Important
properly on the SCSI bus. An inadequate terminator will result in various SCSI bus issues,
including bus hangs and Read/Write failures. See the individual Product Manuals at
www.tandbergdata.com
Notes: You must install a terminator on the device at the physical end of the SCSI bus. If one of the tape drives in
the library terminates the SCSI bus, you must install the required terminator on one of the tape drive's
SCSI connectors. If there are additional devices on the SCSI bus, ensure that only the device at the
physical end of the bus is terminated.
The library communicates with the host through the SCSI interface of one of the tape drive via the
Automation Drive Interface (ADI) serial interface.
See the tape drive's Product Manual for tape drive information.
IBM —
Hewlett Packard —
See Automation/Drive Interface for ADI information:
3. Reconnect the power cord and power on the library (press the
4. Power on the host.
and Figure 14 on page
Quantity
The library requires both the SCSI cover plates and the tape drive cover plates for
ESD protection. Do not leave any openings uncovered.
www.storage.ibm.com/tape/lto/oem/index.html
www1.hp.com/storage/tapestorage.html
11.
Attach this SCSI cover plate...
Location
Two None
One Top
for detailed information.
www.T10.org
I
External drive label
None
Drive 2
on the back of the unit).
"Tape
a
15 16
