Term
O
Occupied points for
the module
input/output
P
Paring
PID
PLC
S
Short circuit detection
Short circuit
protection
R
Refresh button
Reset button
Remote Control
W Wireless channel
Wireless Base
Wireless Remote
Wireless unit
Number of I/O points that can be controlled by a module.
Registration of the PID (Product ID) of the Wireless Remote unit to be connected to the
Wireless Base unit. Registration occurs at the initial setting, then wireless system will
activate.
Abbreviation of Product ID. A 32 bit digit sequence which is assigned to identify the
wireless unit (Base/Remote unit).
Abbreviation of Programmable Logic Controller. A digital computer used for automation
of electromechanical processes.
Diagnostic function which detects generation of over current due to a short circuit
between the output and the positive power supply line or the ground line.
Function which avoids damage to the internal circuit when over current is generated
due to short circuit between the output and the positive power supply line or the ground
line.
Button to display the latest configuration of the wireless units, as set by the I/O
configurator for NFC.
Button to update the wireless units with the latest configuration set by the I/O
configurator for NFC. Note: Restarting the wireless unit will also activate the latest
configuration.
The mode to respond to the commands of BOOTP/DHCP Server provided by Rockwell
Automation. It is possible to set parameters for arbitrary Gateway address and Subnet
Mask.
Identification number of the Wireless Remote unit connected to the Wireless Base unit.
A unit which establishes wireless communication of input or output data to the Wireless
Remote. It is connected to a PLC to establish communication of input or output data.
A unit which establishes wireless communication of input or output data to the Wireless
Base.
A unit which establishes wireless communication. This is a generic name of the
Wireless Base and Remote units.
-6-
Definition
