4.3. Forced output

4.3.1. Forced output conditions

The I/O configurator for NFC can directly command the Wireless Base/Remote.
Operating conditions for Forced output.
Forced output Login from the Administrator mode.
conditions Not connected with the higher PLC by Ethernet.
Applicable item for
Wireless Base/Remote
forced output

4.3.2. Forced output procedure

This is the forced output procedure using individual bits. Change the tab to I/O monitor to move to forced
output mode. Then, click "Enforce ON" on the upper right of the window. Then Click Yes.
The window below appears when the mode is changed to forced output mode. Select the output unit to be
forced output and double click it.
[Forced output from the Wireless Base] [Forced output from the Wireless Remote]
Login from the Administrator mode.
Not wirelessly connected with Wireless Base.
Wireless Remote
Double-click
