13.2 Wiring

22K EOL
B+B- A+A- B+B- A+A-
OUTPUT 2
OUTPUT 1
TS1 TS3 TS2
OUTPUT 1 BACKUP OUTPUT 2
IN
B+ B- A+ A- + - B+ B- A+ A-
QAD-30 #2
Secondary Amplifier
Figure 131 Wiring 2 amplifiers to the splitter

13.3 Configuration Steps

To configure the splitter, you must perform the following steps:
• FX-3500 Configuration
•
•
• QX-mini Configuration
•
•
•
•
•
Details on how to perform these steps are in the following pages.
90
B+B- A+A-
OUTPUT 1
TS1
OUTPUT 1
B+ B- A+ A-
Master Amplifier
Assign the AP Start Range
Configure the Output and Input Modules
Create Job
Create Zones and Correlate them to Master Splitter Outputs
Add Inputs for Splitter Outputs
Create Messages
Assign Zones and Messages to Inputs
QAS-2X8 Splitter Configuration - QX-mini and FX-3500 - Two Stage
