Table 1 FX-3500 Output Modules Example
Address Address
in in
FX-3500 QX-mini
201 101
202 102
203 103
204 104
205 105
206 106
281 181
282 182
283 183
284 184
285 185
286 186
287 187
288 188
291 191
292 192
92
Device
Relay Output Module
(CLIP)
Input Module (CLIP)
Input Module (CLIP)
Input Module (CLIP)
Input Module (CLIP)
Input Module (CLIP)
Supervised Output
Module (CLIP)
Supervised Output
Module (CLIP)
Supervised Output
Module (CLIP)
Supervised Output
Module (CLIP)
Supervised Output
Module (CLIP)
Supervised Output
Module (CLIP)
Supervised Output
Module (CLIP)
Supervised Output
Module (CLIP)
Relay Output Module
(CLIP)
Relay Output Module
(CLIP)
QAS-2X8 Splitter Configuration - QX-mini and FX-3500 - Two Stage
Type Tag
QX-mini
Relay
Signal Silence
Trouble QX-mini AC
Input Power Fail
Building/
QX-mini
Property
Paging Active
Safety
QX-mini
Trouble
Common
Input
Trouble
QX-mini
Trouble
Battery
Input
Trouble
QX-mini
Trouble
Ground Fault
Input
Trouble
Signal Floor 1 Alert
Signal Floor 2 Alert
Signal Floor 3 Alert
Signal Floor 4 Alert
Signal Floor 5 Alert
Signal Floor 6 Alert
Signal Floor 7 Alert
Signal Floor 8 Alert
Relay Floor 1 Evac
Relay Floor 2 Evac
Alarm Status
Correlations Correlations
Signal Silence
Detectors on Fire Drill, Total
floors 1 to 8 Evacuation
Detectors on Fire Drill, Total
floors 1 to 8 Evacuation
Detectors on Fire Drill, Total
floors 1 to 8 Evacuation
Detectors on Fire Drill, Total
floors 1 to 8 Evacuation
Detectors on Fire Drill, Total
floors 1 to 8 Evacuation
Detectors on Fire Drill, Total
floors 1 to 8 Evacuation
Detectors on Fire Drill, Total
floors 1 to 8 Evacuation
Detectors on Fire Drill, Total
floors 1 to 8 Evacuation
Detectors on Total
floors 1 and 2 Evacuation
Detectors on
Total
floors 1, 2 and
Evacuation
3
