4.3.2 QX-mini Steps
Note:
1.
Open MGC ECS configurator.
2.
Open an existing job or create a new job.
3.
Select a unique password that will be assigned to the job specifically.
4.
Define timing for page inhibit delay as per requirements.
5.
Select either Class A or Class B depending on the inter-panel wiring.
6.
Click on "New Job" or "Edit Job" for an existing file and choose the SLC Type (Series:
FX-3500/FX-2000/FleX-Net™/MR-3500).
Figure 33 New Job window
7.
Click on "Master Panel 0" and then click "Edit".
Until the QX-mini Master is connected and configured, missing device
troubles can be ignored.
SLC Integration - QX-mini and FleX-Net™ - Two Stage
23
