3.
Serial port is automatically detected. Click "OK".
Figure 18 Serial port
2.6
Sending a Job
!
Attention: You must send the job to the Master and Booster panels individually.
1.
Click "Send Job".
Figure 19 Send Job button
2.
Do not unplug USB cable until job send is complete and connection is automatically
disconnected.
Figure 20 Please wait 30 seconds while the panel reboots
3.
After job has been successfully sent to panel, connection will be lost. Disconnect the
USB connector and wait for the panel to reboot.
14
Ensure that you are connected to the correct panel before you send the
job.
Working with the Configurator
