PRO3X Equipment View
Alternating Branch Metrics
Alternating phase technology is not available with the PRO3X. However, across the 36 locking outlets,
alternating branch-current metrics are available on all PRO3X units, divided into 18 HDOT and 18 HDOT Cx
outlets.
This means each branch carries a phase. An example of alternating branch in the PRO3X unit design is the
following layout:
L1 > L2 > L3 > L1 > L2 > L3.
PRO3X and Divided HDOT C13 and HDOT Cx Outlets
PRO3X User Guide – Features
8 of 61
