Chapter 2: Outlet Locking (RAMLock)

The RAMLock mechanism provides maximum outlet retention, designed exclusively for the PRO3X with an
innovative, easy-to-use design.
RAMLock Retention Mechanism
RAMLock is an ergonomic locking arm, does not require tools or other locking cords, and allows single-hand
removal of a cord with the quick press of the lever.
RAMLock Outlets on the PRO3X
On the PRO3X PDU, the RAMLock locking outlets are 36 evenly-spaced outlets (18 HDOT C13 and 18 HDOT Cx)
over the length of the entire unit using a self-latching, cam-style locking mechanism.
RAMLock works when the blade of the locking mechanism goes against the shell of the plug. With this
mechanism, RAMLock provides enough retention for security but not so much retention to require tools or both
hands to unplug the cable.
The benefit in the data center is the easy and convenient retaining of a cable using only one hand. In addition,
RAMLock cords cannot be bumped or vibrated out.
