Omron S8FS-C Series Manual page 30

S8FS-C
S82Y-FSC050DIN
S82Y-FSC150DIN
75W/100W
3.9 (Sliding: 6.6 max.)
5.1 (Sliding: 7.8 max.)
S82Y-FSC350DIN
30
(12)
50W
35W
50W
4.5 (Sliding: 7.2 max.)
5.5 (Sliding: 8.2 max.)
(12)
150W
(12)
75W/100W
150W
75W/100W
150W
(12)
200W/350W
4.5 (Sliding: 7.2 max.)
147.7
(12)
117.7
3.5 dia. (35W)
35W 3.5 dia. (50W)
50W 35W
112.5
±1
217.7
177.7
Four, 3.5 dia.
165.5 ±1
230.7
Four, 4.5 dia.
210.5
±1
Mounting Method
5
48.5
49.5
85.5
±1
48.5
47.5
Accessories (2 locations)
Be sure to use the accessory screws.
Mounting screw tightening torque:
0.48 to 0.59 N·m for M3 screws
39.2
37.2
35.2
±1
5 max.
Mounting Method
5
47.9
49.1
98.5 ±1
47.9
49.1
Accessories (4 locations)
Be sure to use the accessory screws.
Mounting screw tightening torque:
39.2
0.48 to 0.59 N·m for M3 screws
36.7 ±1
5 max.
Mounting Method
5
56.25
94.75
±1
56.25
Accessories (4 locations)
Be sure to use the accessory screws.
Mounting screw tightening torque:
1.08 to 1.32 N·m for M4 screws
51.2
49.2
±1
5 max.
