S8FS-C
Construction and Nomenclature
Nomenclature
25-W, 35-W, 50-W,
15-W Models
and 75-W Models
S8FS-C025
S8FS-C035
4
5
1
3
2
S8FS-C015
S8FS-C025
S8FS-C035
No.
1
Input terminals (L), (N)
2
Protective Earth Terminal (PE)
3
DC output terminals (−V), (+V)
4
Output indicator (DC ON: Green)
5
Output voltage adjuster (V. ADJ)
6
Input voltage selector switch
*1. The fuse is located on the (L) side. It is not user replaceable. For a DC power input, connect the positive voltage to the L terminal.
*2. This is the protective earth terminal specified in the safety standards. Always ground this terminal.
*3. The 100-W, 150-W, 200-W, and 350-W models only.
*4. Refer to Input Voltage Selector Switch in Safety Precautions on page 36.
16
100-W and 150-W Models
4
5
1
2
3
S8FS-C050
S8FS-C075
4
5
1
2
3
S8FS-C050
S8FS-C075
Name
Connect the input lines to these terminals. *1
Connect the ground line to this terminal. *2
Connect the load lines to these terminals.
Lit while the DC output is ON.
Use to adjust the output voltage.
Used to switch the input voltage. *3, *4
6
1
2
3
S8FS-C100
S8FS-C150
6
1
2
3
S8FS-C100
S8FS-C150
6
200-W and 350-W Models
4
4
5
5
3
S8FS-C200
S8FS-C350
4
4
5
5
3
S8FS-C200
S8FS-C350
Function
6
1
2
6
1
2
