S8FS-C
Ordering Information
List of Models
Note: For details on normal stock models, contact your nearest OMRON representative.
Power rating Input voltage
15 W
25 W
100 to 240 VAC
35 W
(allowable range:
85 to 264 VAC or
120 to 370 VDC
*1)
50 W
75 W
100 to 120 VAC,
200 to 240 VAC
(allowable range:
85 to 132 VAC,
100 W
176 to 264 VAC, or
248 to 373 VDC
(Select with the switch.)
*2)
150 W
100 to 120 VAC,
200 to 240 VAC
(allowable range:
90 to 132 VAC,
180 to 264 VAC, or
200 W
254 to 373 VDC
(Select with the switch.)
*2)
350 W
Note: You can use brackets that are sold separately to mount the Power Supplies to DIN Rail. Refer to Mounting Brackets (Order Separately) on
page 29.
*1. The range for compliance with EC Directives and safety standards (UL, EN, etc.) is 100 to 240 VAC.
*2. The range for compliance with EC Directives and safety standards (UL, EN, etc.) is 100 to 120 VAC, 200 to 240 VAC.
2
Output voltage
Output current
(VDC)
5 V 3 A
12 V 1.3 A
15 V 1 A
24 V 0.7 A
5 V 5 A
12 V 2.1 A
15 V 1.7 A
24 V 1.1 A
5 V 7 A
12 V 3 A
15 V 2.4 A
24 V 1.5 A
5 V 10 A
12 V 4.2 A
15 V 3.4 A
24 V 2.2 A
48 V 1.1 A
5 V 14 A
12 V 6.2 A
15 V 5 A
24 V 3.2 A
48 V 1.6 A
5 V 20 A
12 V 8.5 A
15 V 7 A
24 V 4.5 A
36 V 2.8 A
48 V 2.3 A
5 V 26 A
12 V 12.5 A
15 V 10 A
24 V 6.5 A
36 V 4.3 A
48 V 3.3 A
5 V 40 A
12 V 17 A
24 V 8.8 A
36 V 5.9 A
48 V 4.43 A
5 V 60 A
12 V 29 A
24 V 14.6 A
36 V 9.7 A
48 V 7.32 A
Model with
Built-in fan terminal block
facing upward
S8FS-C01505J S8FS-C01505D
S8FS-C01512J S8FS-C01512D
---
S8FS-C01515J S8FS-C01515D
S8FS-C01524J S8FS-C01524D
S8FS-C02505 S8FS-C02505J S8FS-C02505D
S8FS-C02512 S8FS-C02512J S8FS-C02512D
S8FS-C02515 S8FS-C02515J S8FS-C02515D
S8FS-C02524 S8FS-C02524J S8FS-C02524D
S8FS-C03505 S8FS-C03505J S8FS-C03505D
S8FS-C03512 S8FS-C03512J S8FS-C03512D
S8FS-C03515 S8FS-C03515J S8FS-C03515D
S8FS-C03524 S8FS-C03524J S8FS-C03524D
S8FS-C05005 S8FS-C05005J S8FS-C05005D
S8FS-C05012 S8FS-C05012J S8FS-C05012D
S8FS-C05015 S8FS-C05015J S8FS-C05015D
S8FS-C05024 S8FS-C05024J S8FS-C05024D
S8FS-C05048 S8FS-C05048J S8FS-C05048D
S8FS-C07505 S8FS-C07505J S8FS-C07505D
S8FS-C07512 S8FS-C07512J S8FS-C07512D
None S8FS-C07515 S8FS-C07515J S8FS-C07515D
S8FS-C07524 S8FS-C07524J S8FS-C07524D
S8FS-C07548 S8FS-C07548J S8FS-C07548D
S8FS-C10005 S8FS-C10005J S8FS-C10005D
S8FS-C10012 S8FS-C10012J S8FS-C10012D
S8FS-C10015 S8FS-C10015J S8FS-C10015D
S8FS-C10024 S8FS-C10024J S8FS-C10024D
S8FS-C10036 S8FS-C10036J S8FS-C10036D
S8FS-C10048 S8FS-C10048J S8FS-C10048D
S8FS-C15005 S8FS-C15005J S8FS-C15005D
S8FS-C15012 S8FS-C15012J S8FS-C15012D
S8FS-C15015 S8FS-C15015J S8FS-C15015D
S8FS-C15024 S8FS-C15024J S8FS-C15024D
S8FS-C15036 S8FS-C15036J S8FS-C15036D
S8FS-C15048 S8FS-C15048J S8FS-C15048D
S8FS-C20005 S8FS-C20005J S8FS-C20005D
S8FS-C20012 S8FS-C20012J S8FS-C20012D
S8FS-C20024 S8FS-C20024J S8FS-C20024D
S8FS-C20036 S8FS-C20036J S8FS-C20036D
S8FS-C20048 S8FS-C20048J S8FS-C20048D
S8FS-C35005 S8FS-C35005J S8FS-C35005D
S8FS-C35012 S8FS-C35012J S8FS-C35012D
Yes S8FS-C35024 S8FS-C35024J S8FS-C35024D
S8FS-C35036 S8FS-C35036J S8FS-C35036D
S8FS-C35048 S8FS-C35048J S8FS-C35048D
Model with
Model wtih
terminal block
DIN rail
facing forward
