1 Base Assembly
1.1 Motor holder assembly
Name
Motor holder
Motor holder support
Square nut
M3 x 16 Screw
M3 washer
Step1. Assemble A3 and 2 A4 together, and screw up with M3 x 16 screws, M3 square
nut and M3 washer.
www.geeetech.com
ShenZhen GETECH CO.,LTD
GEEETECH
Part NO.
qty
NO.A3
3
NO.A4
6
NO.13
6
NO.20
6
NO.5
6
Tel: +86 755 2658 4110
Pic
Fax: +86 755 2658 4074 - 858
5
