Lutron Electronics HomeWorks Protocol Manual page 83

RSVS
RSVS
Syntax
RSVS, <address>
Processor responds with
SVS, <address>, <scene command>, <status>
Parameter Description
address system address of Sivoia control to query
scene Sivoia scene command currently selected
command on the Sivoia
status current status of the scene command
Description
Returns the current scene command and status on the specified Sivoia
Example
Request the current scene command for processor 1, link 6, Sivoia control address 4
Response is stopped at Preset 2
L232> RSVS, [1:6:4]
SVS, [01:06:04], 2, STOPPED
See Also
SVSS -Select a Sivoia scene command
http://www.lutron.com/hwi/Help/l232/rsvs.htm [7/3/03 1:20:05 PM]
Request a Sivoia's Current
Scene Command
Format
[processor : link : address]
see device address formatting
description
1 = Preset 1
2 = Preset 2
3 = Preset 3
R = Raise
L = Lower
C = Close
o = Open
S = Stop
STOPPED or MOVING
