RKLS
RKLS
Syntax
RKLS, <address>
Processor Response
KLS, <address>, <led states>
Parameter Description
address system address of the keypad
led states the current state of the keypad's LEDs
Description
Queries the system for the state of the LEDs on a specified keypad. 24 led digits will be
returned regardlessof the number of physical leds on the keypad.
Example
Query processor 4, link 6, keypad 1
L232> RKLS, [4:6:1]
KLS, [04:06:01], 000001000010000010000000
See Also
SETLED - Set keypad LED state
http://www.lutron.com/hwi/Help/l232/rkls.htm [7/3/03 1:20:02 PM]
Request a Keypad's LED
Format
[processor : link : address]
see device address formatting
The first digit is LED 1, the last digit is LED
24
0 = Off
1 = On
2 = Flash 1
3 = Flash 2
States
description
