Lutron Electronics HomeWorks Protocol Manual page 63

RDL
RDL
Syntax
RDL, <address>
Processor responds with
DL, <address>, <level>
Parameter Description
address system address of zone to query [processor : link : interface : module or bus :
level current level of the queried zone 0 - 100 (percent)
Description
Returns the current or target level for any zone in the sysyem
Example
Request the current intensity of processor 1, link 1, MI address 0, RPM module 2, zone 4
L232> RDL, [1:1:0:2:4]
DL, [01:01:00:02:04], 50
See Also
FRPM - Fade an RPM Dimmer
FV - Fade Vareo Dimmer
http://www.lutron.com/hwi/Help/l232/rdl.htm [7/3/03 1:19:57 PM]
Request a Dimmer Level
Format
zone]
see device address formatting description
